Abstract

This page presents an experiment comparing the performance of Slicer 2.6 and Slicer 3.4 binary release and Slicer3.4 build-from-source(current version) EM segmentation modules on non-human data. Sept, 09.

Experiment description

DATA:

Experiment done on subject Oscar. This subject was used as the target in generating template, so the template and target are perfectly aligned. As a result, by choosing this subject, the effect of template-to-target mis-alignment in segmentation is removed. The resulted difference between Slicer 2 and 3 EM will purely reflect the performance of the segmentation modules.

Procedure

Data is first segmented in Slicer 3. The parameters are manually chosen (by selecting samples, etc.) for the best segmentation performance. The exact parameter are copied to perform the same segmentation in Slicer 2.

EMsegmentation parameters in Slicer 3 : (Global prior | atlas weight) {log mean | log covariance} [label]

(Same EMsegmentation parameters in Slicer 2 : (prob | prob data weight) {mean | covariance} [label] )

 whole head
   |_ECC (0.4 1) {2.9317, 1.7046} [l:0]
   |_ICC (0.6 1)
       |_GM (0.4 0.7)
       |  |_GMwoHPC (0.66 0.6) {3.5549,0.02454} [l:7]
       |  |_HP (0.07 0.6) {3.747,0.00214} [l:4]
       |  |_Caudate (0.17 0.6) {3.6354,0.00456} [l:5]
       |  |_Putamen (0.1 0.6) {3.7522,0.00456} [l:6]
       |_WM (0.3 0.7) {3.9028,0.00548} [l:2]
       |_CSF (0.3 0.7) {2.805,0.23349} [l:3]
